Product images. including color, may differ from actual product apperance
Best Wholesale prices for Jewelers on the internet !
Our Price: $865.00
Sale Price: $865.00

Product Code: R44

We have started utilizing a unique hardening procedure which allows us to market superior rollers that will perform beautifully. Our rollers are made from a high quality carbon steel alloy that offers excellent wear resistance and the outer 3mm of the rolls are hardened to around 60 HRC for superior deformation resistance.
Our new units are all powder coated for superior corrosion protection and appearance. Pepetools rolling mills feature true gear reduction with easily turned short handles.
  • Gear ratio 4:1
  • Roller diameter 55 mm
  • Roller width is 110 mm
  • Maximum opening 0-5 mm
  • Flat area (± 0.01mm) 57 mm
  • Square wire (± 0.01mm) : 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0
  • Ring shank - half round ellipsis: 2.5 x 1:3 x 1.25 ; 4 x 1.5
  • Capable of producing metal foil as thin as .001''

Average Customer Review: Average Customer Review: 4 of 5 4 of 5 Total Reviews: 2 Write a review.

  0 of 0 people found the following review helpful:
3 of 5 Okay Medium Duty Mill January 15, 2016
Reviewer: Mike Edelman from Frostburg, MD United States
Before I go into the main review, I want to be clear this mill may be returned because it was incorrectly advertised--it was advertised as having 7 square wire slots, but only has 6, with a full 1mm jump between two of them making rolling tapers impossible.

This rolling mill is as expected, sort of a middle of the road mill. I have used the cheap low end ones and I own a Durston. This mill, though actually having a larger working area than my Durston, has a MUCH smaller frame thickness. It operates smoothly, has much nicer made rollers and gears than the low end mills, but if you are a strong person that aggressively needs to use a mill, this one is not for you.

It is not a bad mill, I'm optimistic that either Pepe or the Jewelers Toy Store will address the issue with being shipped the wrong rollers--if neither company does than I would be wary based on post purchase customer service issues (i'll edit this review once this issue is resolved).

Was this review helpful to you?

  1 of 1 people found the following review helpful:
5 of 5 i just want to buy this roll mill 110mm combine November 22, 2011
Reviewer: Raad from , Norway
i wonder to know, how can i buy combine roll ill 110mm ? from this site please need your help ? send me to (xray.2008@yahoo.com ) or call me 0047 45521060  .am ,Raad ,from Norway

Was this review helpful to you?
